Open the VNC-Viewer software as shown on the figure below.
You can use the VNC-Viewer software in Windows to control Chipsee IPC over Ethernet.
In this tutorial, we will use the XShell tool to perform SSH debugging. You can configure XShell or you can directly use the SSH tool in Linux OS. Get the IP address of the Chipsee IPC product. To perform SSH debugging on the Chipsee IPC, you must first connect the product to the Internet.Ĭontinue the debugging by follow these steps: Open XShell and use the session properties as shown on the figure below.
Qt reader download how to#
Please reference the How To Connect Board By Serial manual to connect your PC and Chipsee Industrial Computer over a serial cable. You can use RS232_1_TXD, RS232_1_RXD, GND.įollow these steps to perform serial debugging:Ĭonnect your Windows PC to the Chipsee IPC over a serial cable. You can use it to debug directly, and the default user and password is. The debug serial port of Chipsee Industrial Computer is the first RS232 port. You can refer to the RS232/RS485/CAN Connector section under the EPC/PPC-A7-70HB-C manual to understand the serial ports of the IPC. You can also use other tools such as Putty, Minicom, SecureCRT or any terminal emulation software. In this document, we use Xshell to debug the Chipsee Industrial Computer. In this documentation, all the commands are executed with root user privileges. Xshell or other terminal emulation software Linux Qt 5.5 OS Prebuilt Files Package (from the link above) USB A-A cable (used only if the hardware configured as OTG) USB-to-serial or other serial cable for debugging You need to prepare the Power Adapter by yourself Hardware Requirements ¶ The CS10600U070 product needs a 6V to 36V power adapter. Power Supply Unit (PSU) with the appropriate voltages, as follows: You will need to prepare the following items before you can start using the Prebuilt Files Package to re-flash the system. Downloading Images by using the TF cardīelow is the link to the prebuilt images for the Linux Qt operating system on the various industrial PC.Powered by Arm Cortex, Intel, and Raspberry PI platforms.
